MORTERPLAS FP 4,8 KG

MORTERPLAS FP 4,8 KG plastomeric bitumen-based waterproofing membrane with non-woven polyester felt reinforcement.

Technical documentation

  • Logo Facebook
  • Logo Twitter
  • Logo Linkedin
  • Advantages
  • Application
  • Installation
  • Storage
  • Regulations
.High softening point and excellent behaviour
under high temperatures, making it ideal for
application during the summer
.Great flexibility
.Particularly suitable for roofs with slow
deformation
.Excellent durability and ageing
.Resistance to extremely high and low
temperatures
It is especially recommended in applications where maximum puncturing resistance is needed.
· MORTERPLAS FP can be applied in a double-layer system on non-trafficable and trafficable roofs for pedestrians and vehicles, with heavy protection.
· For single-layer systems, membranes with a mass ≥ 4 kg will be used in systems in accordance with the DITs and local construction regulations.
· MORTERPLAS FP 4,8 KG is especially indicated for application on roofs with zero slope, with systems in accordance with DIT [Technical Suitability Document] No. 562/10.
· SUPPORT: The surface must be dry, firm, even, clean and free of loose materials.
· It can be applied completely adhered, partially adhered or floating. · To adhere the membrane to the support, the support is primed with EMUFAL I. Once dry, use flame to adhere the membrane.
· The flame is applied as uniformly as possible (the greater the heat, the greater the retraction) along the width of the membrane without reaching the overlap, which will be done later, since it is important that the temperature be the same in every area. The flame should be applied until the anti-adherent film pore opens.
· The membranes are installed in such a way that no more than three membranes overlap at the same point.
· Overlaps are flame-bonded, with a minimum overlap of 8 cm.
· In the two-layer solution, the top membrane must be completely adhered to the bottom membrane, and it must be placed in the same direction so that the overlap lays approximately in the middle of the bottom membrane.
· Installation and measurements will be conducted in accordance with regulations of the UNE 104401 standard.
Roll: 1 m x 8 m
Pallet: 216 m²
· In accordance with the EN 13707, EN 13969 and EN 13859-2 standards. Certified with CE marking No. 0099/CPR/A85/0087
· Voluntary certification of the product with AENOR seal according to the same European standard.
· With DIT No. 516 Inverted roof systems “TEXLOSA® ROOFING SYSTEMS.”
· With DIT No. 562/10 MORTERPLAS/MOPLAS ZERO slope
· With DIT No. 579/11 MORTERPLAS VEHICULAR TRAFFIC
· With DIT No. 580/11 UNDERGROUND STRUCTURES MORTERPLAS
· Quality System in accordance with ISO:9001
